TLAM-070110-0618-1.0
TLAM-070110-0618-1.0 is an active X6 frequency multiplier. The multiplier has an input frequency of 11.16 to 18.34 GHz with a typical input power of 3 dBm and an output frequency of 70 to 110 GHz with a typical output power of +18 dBm. The DC power requirement for the multiplier is +16 V DC. The input port configuration is a female 1.85mm connector and the output is a female 1.0mm connector.
Output frequency (GHz)70-110
Output power (dBm)18
Input power (dBm)3
Output Connector1.0mm Female
Specification Click to download the specification
