TBG-80160-3S-180

Frequency(GHz) Min	8
Frequency(GHz) Max	16
Isolation(dB)	19
Insert. Loss(dB)	1.3
Phase Balance(°)	8
Amp Balance(dB)	0.9
VSWR	1.3
Connector	SMA
Power(W)	30
Operating Temperature	-45-+85℃
Specification	Click to download the specification
