TLBF-1G3-700K-E
Bandpass filter TLBF-1G3-700K-E is a high-frequency band-pass filter with a center frequency of 1300MHz and a band-pass bandwidth of 0.7MHz. The insertion loss of this model of filter is less than 12dB and the rejection rate is more than 50dB. SMA-Female connector is adopted.
Center Frequency (MHz)1300
Bandwidth (MHz)0.7
Out of band suppression (dB)>50dB@FC±10MHz
Insert. Loss(dB)12
Connector Type1SMA Femlae
In band fluctuation (DB)0
Specification Click to download the specification
