TLLA2G40G-27-50
TLLA2G40G-27-50 is a low noise amplifier with a typical small signal gain of 27 dB and a nominal noise figure of 5.0 dB across the frequency range of 2 to 40 GHz. The DC power requirement for the amplifier is +12 V DC/250 mA. The input and output port configuration offers coax adapter structure with 2.92mm female.
Frequency(GHz) Min2
Frequency(GHz) Max40
Gain (dB)27
Gain flatness (± dB)2.5
Noise Figure (dB)5
P1dB(dBm)17
VSWR2
Connector2.92mm
Specification Click to download the specification
