Home > Products > mmWave and Terahertz Components > Millimeter Waveguide mixer > Subharmonic Mixers > TLHM-140220-0240-05

TLHM-140220-0240-05

The TLHM-140220-0240-05 is a terahertz subharmonic mixer with an RF frequency range of 140-220GHz harmonic coefficient 2 and conversion loss -12dB. Tele Microwave offers harmonic mixer solutions up to 650GHz terahertz.

RF frequency (GHz)	140-220
LO frequency (GHz)	70-110
Harmonics(dBc)	2
Frequency conversion loss (DB)	-12
RF Connectors	WR5
Specification	Click to download the specification
